With Megger SVERKER units, you’ll have everything you need to test practically any single-phase relay protection. This relay test set is suitable for use with overcurrent, inverse time, undercurrent, ground fault, directional overcurrent, directional ground fault, overvoltage, undervoltage, directional power and a wide variety of other single-phase protection. It’s also suitable for use on three-phase protection – just use the SVERKER780 on one phase at a time or alternatively this relay tester is also suitable for use on phase-shifting protective relay systems plus automatic reclosing devices.
The Megger SVERKER780 relay tester is equipped with every measurement function you’ll need, all shown in real time on the built-in LCD digital display. This powerful measurement section can display (in addition to time, voltage and current) Z, R, X, S, P, Q, phase angle and cos φ. An integrated voltmeter and ammeter are included for measurements, with the possibility to use the voltmeter as a second ammeter (ideal for testing differential relays).
Need to make a log of your results? No problem with the SVERKER780 – hook the relay tester up to your PC via the built-in serial connection to export your results into Excel documents or use Megger’s SVERKER Win software (sold separately) to create fully customisable reports and log data in real-time.
Megger SVERKER780 Relay Test Set Key Features
Portable solution for testing a wide variety of single phase relays
Variable frequency and continuous phase shift functions
Built-in carrying handle for easy transportation
Rugged and reliable design for field use
Logical design with simple interface
Display can show time, voltage, current, Z, R, X, S, P, Q, phase angle and cos φ
Intergated voltmeter and ammeter
Variable voltage source
Serial port for communication with PC and SVERKER Win PC software (software sold separately)
Two SVERKER units can be synchronised to create a basic 3-phase test set
Suitable for voltage relays with frequency range from 15Hz up to 550Hz
Use to plot excitation curves
Suitable for burden measurements on protective relays
Impedance, efficiency and polarity measurement possible
What’s Included?
Megger SVERKER780 Relay Test Set (230V)
Test Lead Set (GA-00030)
Transport Case
Optional Accessories
CD-8102X: SVERKER Win PC Software + RS232/USB Cables (please specify SVERKER serial number when ordering)
CSU20A: 230V Current and Voltage Source
PSS750: Phase Selector Switch
AA-00100: Cable Organiser (Velcro Straps x 10)
